SECTION 7.5REFLECTIONS AND LINESYMMETRY
©Copyright All Rights Reserved to Homework Depot at www.BCMath.ca
REFLECTIONS
A flip/transformation in a mirror line (reflection line)
Objects reflected over a mirror line will look symmetrical
Mirror Line
Object
©Copyright All Rights Reserved to Homework Depot at www.BCMath.ca
LINE OF SYMMETRY
A line that divides an image in half
Both sides of the image look the same over the line(symmetrical)
Line of Symmetry
Everything on theleft side of the
line of symmetry
is equal to everything
on the right side ofthe line of symmetry
©Copyright All Rights Reserved to Homework Depot at www.BCMath.ca
EXAMPLES OF SYMMETRY IN ART
Cup or faces paradox
Paintings, Grafiti
Architecture: Taj Mahul, Acropolis
©Copyright All Rights Reserved to Homework Depot at www.BCMath.ca
EX: DRAW THE LINES OF SYMMETRY FOR EACH OF THE FOLLOWINGSHAPES
3 lines ofsymmetry
5 lines ofsymmetry
4 lines ofsymmetry
NO lines ofsymmetry
1 line ofsymmetry
Any line that goes throughthe center is a line of symmetry
Infinite # oflines of symmetry
©Copyright All Rights Reserved to Homework Depot at www.BCMath.ca
EX: GRAPH EACH IMAGE OVER THE LINE OF SYMMETRY.
D
©Copyright All Rights Reserved to Homework Depot at www.BCMath.ca
III) TYPES OF REFLECTIONS
Horizontal Reflections
Image is reflected sideways (left/right)
Reflected over the Y-axis or any vertical line
Vertical Reflection
Image is reflected upside down
Reflected over the X-axis orany horizontal line
Diagonal Reflection
Image is reflected over a slantedline at y=x
Up Right, Down left
x
y
-5
-4
-3
-2
-1
0
1
2
3
4
5
-5
-4
-3
-2
-1
1
2
3
4
5
©Copyright All Rights Reserved to Homework Depot at www.BCMath.ca
EX: GIVEN FOLLOWING DIAGRAM, DRAW THE IMAGE AFTERTHE REFLECTION OVER THE X-AXIS. LABEL THE COORDINATESOF THE IMAGE:
x
y
-5
-4
-3
-2
-1
0
1
2
3
4
5
-5
-4
-3
-2
-1
1
2
3
4
5
Objects reflected over theline of symmetry will beequal distances from it
After the image is drawn,find the coordinates ofeach vertex
©Copyright All Rights Reserved to Homework Depot at www.BCMath.ca
EX: GIVEN FOLLOWING DIAGRAM, DRAW THE IMAGE AFTERTHE REFLECTION OVER THE LINE X=1. LABEL THECOORDINATES OF THE IMAGE:
x
y
-5
-4
-3
-2
-1
0
1
2
3
4
5
-5
-4
-3
-2
-1
1
2
3
4
5
The line x = 1 is a verticalline with a x-intercept of 1
Reflect each vertex overthe line of reflection
After the image is drawn,find the coordinates ofeach vertex
©Copyright All Rights Reserved to Homework Depot at www.BCMath.ca
EX: GIVEN FOLLOWING DIAGRAM, DRAW THE IMAGE AFTERTHE REFLECTION OVER THE LINE Y=X. LABEL THECOORDINATES OF THE IMAGE:
x
y
-5
-4
-3
-2
-1
0
1
2
3
4
5
-5
-4
-3
-2
-1
1
2
3
4
5
Objects pointing up willbe reflected to the right
Objects pointing down willbe reflected to the left
After the image is drawn,find the coordinates ofeach vertex
©Copyright All Rights Reserved to Homework Depot at www.BCMath.ca
HOMEWORK:
P358 #5, 7 – 9, 11
